Seller's Comment

Tine Cultivator CU3001 Series

On modern farms, cultivation demands have changed. Tight time slots have to be balanced with higher machine performance. Restricted crop rotations call for technology that meets all the requirements of complex cultivation. Kubota’s CU3001 Series Tine Cultivators offer powerful and efficient performance at high forward speeds and consistent working depth. The CU3001 Series has a well-organised tine arrangement over 3 rows with 285 mm spacing that is designed to ensure smooth flow, optimal mixing and intensive seedbed cultivation even with long residues.

Dimensions & Weight

Name	CU3301	CU3351
Working Width	3 m	3.5 m
Transport Width	3 m	3.5 m
Weight w/Cage Roller	1,930 kg	2,170 kg
Weight w/ActiPack Roller	2,080 kg	2,500 kg

Specifications

Name	CU3301	CU3351
Rigid or Folding Frame	Rigid mm	Rigid mm
No. of Tines	10	12
Max. Working Depth	300 mm	300 mm
Distance Between Rows	750 mm	750 mm
Rows of Tines	3	3
Tine Arm	TriFlex 700 w/Auto-Reset	TriFlex 700 w/Auto-Reset
Tine Holder Fixing to Toolbar	Bolted w/Caster Clamp	Bolted w/Caster Clamp
Tine Protection	Non-Stop Leaf Spring (Auto Reset)	Non-Stop Leaf Spring (Auto Reset)
Tine Arm Size (Heat Treated for Strength)	70 x 40 mm	70 x 40 mm
Tine Auto-Reset Breakout Force	700 kg	700 kg
Tine Point (Front Tungsten Plates)	70mm Tiger 2 Point	70mm Tiger 2 Point
Underbeam Clearance	870 mm	870 mm
Average Tine Spacing	285 mm	285 mm
Frame Box Section Size	100 x 100 x 8 mm	100 x 100 x 8 mm
Central Frame Size	N/A mm	N/A mm
Linkage	Cat II & Cat III	Cat II & Cat III
Depth Control (Cage Roller)	550 mm dia.	550 mm dia.
Depth Control (ActiPack Roller)	560 mm dia.	560 mm dia.
Seed Box Fitment Possible	done	done

Standard Extras

Name	CU3301	CU3351
65mm Bolt-on Reversible Point	done	done
Straight Tine Deflectors	done	done
