Power Harrow PH2001 Series

Kubota’s PH2001 Series rigid medium-sized power harrows have a robust, self-supporting trough design for extra strength and trouble-free operation. Two large conical bearings at a wide distance provide rigidity and long service life, while the reliable headstock means easy connection to all tractors and versatile heavy seed drill combinations. The horizontal transmission and self-supporting frame give increased strength, reduced weight and improved centre of gravity for lift capacity.

Dimensions & Weight

Name	PH2301	PH2351	PH2401
Working Width	3 m	3.5 m	4 m
Transport Width	3 m	3.5 m	4 m
Weight w/575mm Packer Roller	1,650 kg	1,825 kg	2,025 kg

Attachment to Tractor

Name	PH2301	PH2351	PH2401
PTO Input Speed	1,000 rpm	1,000 rpm	1,000 rpm
Min. Power Required PTO	85 hp	85 hp	85 hp
Max. Power Allowed PTO	180 hp	180 hp	180 hp
Oscillating Lower Link Size	Cat II	Cat II	Cat II & Cat III

Specifications

Name	PH2301	PH2351	PH2401
Overload Protection	Automatic Clutch	Automatic Clutch	Automatic Clutch
No. of Rotors	12	14	16
No. of Tines	24	28	32
Tine Size	15 x 330 mm	15 x 330 mm	15 x 330 mm
Max. Working Depth	280 mm	280 mm	280 mm
Rotor Speed	336 rpm	336 rpm	336 rpm
Depth Control (Cage Roller)	550 mm dia.	550 mm dia.	550 mm dia.
Depth Control (Packer Roller)	575 mm dia.	575 mm dia.	575 mm dia.
Depth Control (ActiPack Roller)	565 mm dia.	565 mm dia.	565 mm dia.

Standard Extras

Name	PH2301	PH2351	PH2401
Tines	Quick Fit Carbide (Hard Faced)	Quick Fit Carbide (Hard Faced)	Quick Fit Carbide (Hard Faced)
Drive Shaft	GKN 1-3/8" 6 Spline Drive Line With Automatic Clutch	GKN 1-3/8" 6 Spline Drive Line With Automatic Clutch	GKN 1-3/8" 6 Spline Drive Line With Automatic Clutch
Levelling	Rear Levelling Bar w/Extension	Rear Levelling Bar w/Extension	Rear Levelling Bar w/Extension
