Seller's Comment

Kubota U17-3 Mini Excavator

Kubota’s U17-3 zero-tail swing compact excavator gives you the performance and efficiency you need in tight spaces. This compact excavator delivers the power you need, the control you want, and the smooth performance you demand that will help you get the job done more efficiently and more productively.

Engine
Name
U17-3
Engine Type
Tier 4 Compliant
Fuel Type
Diesel
Cylinders
3
Engine Model
Kubota D902-E3
Engine Net
15.1 HP
Engine Gross
16.1 HP
Displacement
898 cc
Rated Speed
2,300 rpm

Drive System
Name
U17-3
Max. Traction Force
2,207 kgf
Tumbler Distance
1,230 mm
Crawler Length
1,585 mm
Shoe Width
230 mm
Ground Contact Pressure (Per cm2)
0.27 kgf

Hydraulics
Name
U17-3
Hydraulic Pump Capacity
17.3 x 2 / 10.41 x 1 l/min
Aux Hydraulic Flow - AUX1
27.7 l/min
Max. Breakout Force - Bucket
1,550 kgf
Max. Breakout Force - Arm
870 kgfSwing System
Name
U17-3
Swing System
Zero Tail Swing
Unit Swing Speed
9.1 rpm
Boom Swing Angle Left
65 degree
Boom Swing Angle Right
58 degree

Travelling Speeds
Name
U17-3
Low
2.1 km/h
High
4.1 km/h

Dimensions
Name
U17-3
Length
3,545 mm
Width
990 mm
Max. Width
1,240 mm
Height - Canopy
2,340 mm
Min. Ground Clearance
150 mm
Operating Weight - Canopy
1,675 kg

Blade
Name
U17-3
Min. Blade Width
990 mm
Max. Blade Width
1,240 mm
Blade Height
260 mm
Max. Lift Above Ground
280 mm
Max. Drop Below Ground
190 mm

Fluid Capacity
Name
U17-3
Fuel Reservoir
19 l
Hydraulic Oil Reservoir
13 l
Hydraulic Oil System
23 l
Engine Oil
3.6 l

Safety Equipment
Name
U17-3
Operator Station
Canopy

Working Range
Name
U17-3
Max. Digging Height
3,540 mm
Max. Dumping Height
2,440 mm
Max. Digging Depth
2,310 mm
Max. Vertical Digging Depth
1,680 mm
Max. Digging Radius At Ground
3,840 mm
Max. Digging Radius
3,900 mm
Min. Turning Radius - w/o Swing
1,440 mm
Min. Turning Radius - Swing
1,215 mm
Min. Tail Turning Radius
620 mm
