Kubota U35-4 Mini Excavator

Have a similar machine to sell? List yours now for $29.00.

POA

Contact Seller in New South Wales

Get answers or find a good time for a test drive. Take the next step and contact the seller.

Request a brochure Can we negotiate on the price?

Add a personal note (optional)

First Name

Email Address

Phone Number

Postcode

Email me price drop and new listings for my search

Receive no-obligation low rate finance quote

First Name

Last Name

Email Address

Phone Number

State

When are you looking to buy a machine?

I agree to the terms & conditions

Getting a quote won't affect your credit score.

Repayment Amount:

Loan Amount:

* Calculated repayment is indicative only.

Find Out More About This Dealer

First Name

Email Address

Phone Number

Postcode

Australian Hammer Supplies

34 Williamson Rd, Ingleburn New South Wales 2565

It is our mission to be New South Wales' most successful Construction & Agricultural Equipment Machinery Company through an absolute commitment to customer service and support.

Australian Hammer Supplies is a family owned and run company specialising in Sales, Parts and Service of Kubota Construction and Agricultural Machinery and Hydraulic Hammers.

Established in 1989, the company has seen significant growth in its operations and sales of Kubota Equipment and Hydraulic Hammers. In 1993 Australian Hammer Supplies became the Australian distributor for Teledyne/Toku Hydraulic Rock Breakers, which is now under the importation of Kubota Tractors Australia.

Price

POA

Need a finance quote?

Getting a quote won't affect your credit score.

Find out more about this dealer?

MINI EXCAVATOR

New South Wales

N/A

Details

Vehicle

Kubota U35-4

Body Type

MINI EXCAVATOR

Condition

New

Cost to Insure

Get a tailored insurance quote with Onesure Insurance Services

34 Williamson Rd, Ingleburn New South Wales 2565

Map

Directions:

Seller's Comment

Kubota U35-4 Mini Excavator

The Kubota U35-4 is a class leading, zero swing excavator offering more room then ever before. Powered by a reliable Kubota 24.8HP engine, the Kubota U35-4 combines superior power and outstanding versatility to tackle a wide variety of jobs and conditions. Handle any job with confidence. Operate auxiliary attachments more easily than ever with precise oil flow control to the auxiliary circuit. More powerful arm breakout force combined with an array of enhanced functions results in the smooth, productive operation Kubota machines are known for.

Engine & Service
Powered by Kubota's impressive 24.8 HP direct injection D1703M-DI-E4 engine (Tier IV compliant). Engineered with the power to maximise digging and lifting performance, it also delivers minimised noise, vibration and fuel consumption.

Thanks to the full-opening rear and right side bonnets, engine, control valves and various components are accessible for easy inspection and repair.Kubota’s attention to user-friendliness can even be found in U35-4’s engine layout. Primary engine components are consolidated onto one side for easier access so inspections and repairs can be made quickly and easily.

Engine
Name
U35-4
Engine Type
Tier 4 Compliant
Fuel Type
Diesel
Cylinders
3
Engine Model
Kubota D1703M-DI-E4
Engine Net
23.9 HP
Engine Gross
24.8 HP
Displacement
1,647 cc
Rated Speed
2,200 rpm

Drive System
Name
U35-4
Max. Traction Force
2,760 kgf
Tumbler Distance
1,670 mm
Crawler Length
2,090 mm
Shoe Width
295 mm
Ground Contact Pressure - Canopy (Per cm2)
0.34 kgf
Ground Contact Pressure - Cab (Per cm2)
0.34 kgf

Hydraulics
Name
U35-4
Hydraulic Pump Capacity
39.6 x 2/ 20.9 x1 l/min
Aux Hydraulic Flow - AUX1
60 l/min
Max. Breakout Force - Bucket
2,810 kgf
Max. Breakout Force - Arm
1,920 kgf

Swing System
Name
U35-4
Swing System
Zero Tail Swing
Unit Swing Speed
8.5 rpm
Boom Swing Angle Left
70 degree
Boom Swing Angle Right
48 degree

Travelling Speeds
Name
U35-4
Low
3 km/h
High
4.6 km/h

Dimensions
Name
U35-4
Length
4,750 mm
Width
1,700 mm
Height - Canopy
2,480 mm
Height - Cab
2,470 mm
Min. Ground Clearance
290 mm
Operating Weight - Canopy
3,850 kg
Operating Weight - Cab
3,996 kg

Blade
Name
U35-4
Max. Blade Width
1,700 mm
Blade Height
340 mm
Max. Lift Above Ground
370 mm
Max. Drop Below Ground
370 mm

Fluid Capacity
Name
U35-4
Fuel Reservoir
45 l
Hydraulic Oil Reservoir
36 l
Hydraulic Oil System
61 l
Engine Oil
5.3 l

Safety Equipment
Name
U35-4
Canopy
Cab

Working Range
Name
U35-4
Max. Digging Height
4,840 mm
Max. Dumping Height
3,400 mm
Max. Digging Depth
3,010 mm
Max. Vertical Digging Depth
2,010 mm
Max. Digging Radius At Ground
5,170 mm
Max. Digging Radius
5,280 mm
Min. Turning Radius - w/o Swing
2,220 mm
Min. Turning Radius - Swing
1,760 mm
Min. Tail Turning Radius
900 mm
