Compact Disc CD1001 Series

The Kubota CD1001 Series Compact Disc is designed for shallower operation at up to 10 cm working depth. It’s 15% lighter than the CD2001, and thus easier to lift, which is economical and ideal for reducing soil compaction. The CD1001 is available in working widths from 2 m to 3.5 m and equipped with a disc arm ready to receive the 520 x 5 mm heat-treated conical disc without lateral movement during work for consistent cutting quality.

Product Features

The Kubota CD1001 Series has a strong main frame design that is carried across the complete rigid CD range. Its light weight makes it easy to lift, resulting in reduced soil compaction. With user-friendly settings, it’s also easy to operate and has good levelling and controlled soil flow.

Dimensions & Weight

Name	CD1201	CD1251	CD1301	CD1351
Working Width	2 m	2.5 m	3 m	3.5 m
Transport Width	2 m	2.5 m	3 m	3.5 m
Weight w/Cage Roller	1,133 kg	1,298 kg	1,462 kg	1,662 kg
Weight w/ActiPack Roller	1,406 kg	1,627 kg	1,854 kg	2,117 kg

Attachment to Tractor

Name	CD1201	CD1251	CD1301	CD1351
Min. Power Required PTO	60 hp	70 hp	90 hp	100 hp
Max. Power Allowed PTO	100 hp	120 hp	150 hp	180 hp
Linkage	Cat II & Cat III	Cat II & Cat III	Cat II & Cat III	Cat II & Cat III

Specifications

Name	CD1201	CD1251	CD1301	CD1351
Disc Diameter and Thickness	520 x 5 mm	520 x 5 mm	520 x 5 mm	520 x 5 mm
No. of Discs	16	20	24	28
Disc Spacing	245 mm	245 mm	245 mm	245 mm
Conical Heat Treated Long Life Discs w/Small Notches	done	done	done	done
Maintenance Free Disc Arm and Double Roller Oblique Bearing Assembly	done	done	done	done
Bearing Hub Seals	5 Lip Seals + 1 Bearing Seal + O-Ring on Bearing Side	5 Lip Seals + 1 Bearing Seal + O-Ring on Bearing Side	5 Lip Seals + 1 Bearing Seal + O-Ring on Bearing Side	5 Lip Seals + 1 Bearing Seal + O-Ring on Bearing Side
Disc Hub Shaft Size	35 mm dia.	35 mm dia.	35 mm dia.	35 mm dia.
Ideal Working Depth	20 – 100 mm	20 – 100 mm	20 – 100 mm	20 – 100 mm
Disc Arm Protection	Rubber Shock 3D Auto-Reset System	Rubber Shock 3D Auto-Reset System	Rubber Shock 3D Auto-Reset System	Rubber Shock 3D Auto-Reset System
Ideal Working Speed – Conditions Dependant	10 – 20 km/h	10 – 20 km/h	10 – 20 km/h	10 – 20 km/h
Inter Gang Distance	900 mm	900 mm	900 mm	900 mm
Disc Gang Frame Box Size	100 x 100 x 8 mm	100 x 100 x 8 mm	100 x 100 x 8 mm	100 x 100 x 8 mm
Depth Control	By Rear Roller	By Rear Roller	By Rear Roller	By Rear Roller
Depth Control Adjustment	Mechanical	Mechanical	Mechanical	Mechanical
Rear Roller Equipment	Cage Roller ø550mm or ActiPack Roller ø565mm	Cage Roller ø550mm or ActiPack Roller ø565mm	Cage Roller ø550mm or ActiPack Roller ø565mm	Cage Roller ø550mm or ActiPack Roller ø565mm
Seed Box Fitment Possible	done	done	done	done
2 Year Factory Machine Warranty	done	done	done	done

Standard Extras

Name	CD1201	CD1251	CD1301	CD1351
Rear Levelling Finger Harrows	done	done	done	done
Adjustable Side Deflector Plates	done	done	done	done
