Disc Spreader DS Weighing Series
Kubota’s DSM-W and DSX-W weighing spreaders have the advantage of speed-related spreading and high-frequency automatic calibration. Hopper volumes range from 1300 to 1875 L, and optional aluminium hopper extensions increase this to 2800 and 4575 L, respectively, depending on the weight of the fertiliser. Spreading width varies from 10 m in the DSM-W1300, to an impressive 54 m, all with even distribution and double overlap. Like our DS standard spreaders, Kubota’s weighing spreaders take advantage of our RotaFlow system, which accelerates the fertiliser granules before they reach the spreading vanes for less impact – all easily controlled via the FlowPilot dashboard.
Specifications
| Name |
DSM-W1300 Geospread |
DSX-W1875 ISOBUS MkII |
DSX-W1875 Geospread MkII |
DSXL-W1875 Geospread Hi-Speed |
| Basic Hopper Capacity |
1,300 L |
1,875 L |
1,875 L |
1,875 L |
| Max. Hopper Capacity |
2,800 L |
4,575 L |
4,575 L |
4,575 L |
| Max. Permissable Weight in Hopper |
2,800 kg |
3,900 kg |
3,900 kg |
3,900 kg |
| Min. Spreading Width |
10 m |
12 m |
12 m |
24 m |
| Max. Spreading Width |
33 m |
54 m |
54 m |
45 m |
| Max. Flow (Fertiliser Density of 1.55kg/L) |
419 kg/min |
356 kg/min |
356 kg/min |
601 kg/min |
| Hopper Width |
2,450 mm |
2,900 mm |
2,900 mm |
2,900 mm |
| Min. Filling Height |
1,130 mm |
1,200 mm |
1,200 mm |
1,200 mm |
| Max. Filling Height |
1,510 mm |
1,960 mm |
1,960 mm |
1,960 mm |
| Weight – Empty |
496 kg |
680 kg |
680 kg |
680 kg |
| Fully ISOBUS Controlled |
done |
done |
done |
done |
| 4 x Load Cells |
2 t |
5 t |
5 t |
5 t |
| Spinner Drive |
PTO w/Clutch |
PTO w/Clutch |
Hydraulic |
Hydraulic |
| Hopper Sieves |
done |
done |
done |
done |
| Slow Rotating Agitator |
done |
done |
done |
done |
| Fine Application Kit |
done |
done |
done |
done |
| LED Road Lighting |
done |
done |
done |
done |
| Spreading Computer |
See Options |
See Options |
See Options |
See Options |
| Hopper Shutter Control |
Electric Actuators |
Electric Actuators |
Electric Actuators |
Electric Actuators |
| Spreading Width Adjustment |
Electric Actuators |
Manual Lever |
Electric Actuators |
Electric Actuators |
| GEOSPREAD Section Control Section Widths |
1 m |
4 m |
1 m |
1 m |
| GEOSPREAD Section Control Max. Sections |
Unlimited |
16 |
Unlimited |
Unlimited |
Standard Extras
| Name |
DSM-W1300 Geospread |
DSX-W1875 ISOBUS MkII |
DSX-W1875 Geospread MkII |
DSXL-W1875 Geospread Hi-Speed |
| Hopper Emptying Kit |
done |
done |
done |
done |
| Lift Vanes |
done |
done |
done |
done |
| Foldable Side Step |
done |
done |
done |
done |
| Mudguards |
done |
done |
done |
done |
| Central Hydraulic Drive – 100cc |
close |
Option |
done |
close |
| Central Hydraulic Drive – 130cc |
close |
close |
close |
done |
