Track Loader

New South Wales

N/A

Details

Vehicle

Kubota SVL97 2

Make

Kubota

Model

SVL97 2

Body Type

Track Loader

Condition

New

State

New South Wales

Cost To Insure

Get a tailored insurance quote with Onesure Insurance Services

34 Williamson Rd, Ingleburn New South Wales 2565

Map

Directions:

Seller's Comment

Track Loader SVL97-2

Powered by a 96.4HP Kubota engine with exceptional 3611KG bucket breakout force and outstanding lifting capacity at 2662KG, the Kubota SVL97-2 delivers superior comfort and performance to tackle any job with ease. Offering superior versatility, the hi flow hydraulics delivering 152.0 l/min to run the largest attachments from tree mulchers to road profilers.

Engine
Powerful Kubota 96.4HP CRS (common rail system) diesel engine. CRS electronically controls the fuel injection timing and amount for high torque at a low RPM, improving work efficiency.

DPF (diesel particulate filter) automatically burns the particulate matter built up in the filter.

Automatic burning can be postponed when the track loader is operating in fire prone areas or hazardous environments.

Updates include a DEF harness bracket design change to reduce friction and vibration, while the harness is now mounted in a different position

The DEF tank has been modified with a capacity of 12L, and now comes standard with a lockable DEF tank cover for the Ad Blue tank.

Engine
Name
SVL97-2
Engine Type
Tier 4 Emission Level
Fuel Type
Diesel
Cylinders
4
Engine Model
Kubota V3800-TIEF4
Engine Net
87 HP
Engine Gross
96.4 HP
Displacement
3,769 cc
Rated Speed
2,400 rpm
Undercarriage
Name
SVL97-2
Track Width - Standard
450 mm
Ground Pressure Cab - Standard Track
4.5 psi
Track Roller (Per Side)
5
Track Ground Contact Length
1,667 mm
Traction Force
5,524 kg
Min. Ground Clearance
293 mm
Hydraulics
Name
SVL97-2
Aux Hydraulic Flow - High
152 l/min
Loader Hydraulic Pressure (Per cm2)
249.8 kgf
Loader Performance
Name
SVL97-2
ROC - 35% Tipping Load
1,451 kg
Tipping Load
4,147 kg
Breakout Force - Bucket
3,458 kg
Breakout Force - Lift Arm
2,509 kg
Lift Arm Path
Vertical
Travelling Speeds
Name
SVL97-2
Low
8 km/h
High
11.7 km/h
Dimensions
Name
SVL97-2
Length
3,137 mm
Width - Standard Track
1,962 mm
Height
2,116 mm
Operating Weight - Cab
5,240 kg
Fluid Capacity
Name
SVL97-2
Fuel Reservoir
109 l
Hydraulic System
68 l
Hydraulic Tank
38.1 l
Safety Equipment
Name
SVL97-2
Cab
Front Sliding Window
