Seller's Comment

M126/M135GX

The new generation MGX Series range delivers class leading power and reliability while reducing environmental impact. With one of the largest cabs in its class, the premium MGX range offers unmatched operator comfort and visibility. Built for maximum power and torque output with intelligent technology, the MGX series is equipped to efficiently handle the most demanding jobs in the field or farm.

Engine

Name	M126GX	M135GX	M135GXS
Fuel Type	Diesel	Diesel	Diesel
Cylinders	4	4	4
Engine Model	Kubota V6108	Kubota V6108	Kubota V6108
Engine Gross	125 hp	135 hp	135 hp
PTO	108 hp	118 hp	118 hp
Displacement	6,124 cc	6,124 cc	6,124 cc
Fuel Tank Capacity	190 l	190 l	190 l
Rated Speed	2,200 rpm	2,200 rpm	2,200 rpm

Drive Train

Name	M126GX	M135GX	M135GXS
Transmission	Powershift	Powershift	Powershift
Ranges	3 Range	3 Range	3 Range
Gears	24F	24F	24F
Drive Method	4WD	4WD	4WD
Brakes	Wet Disc	Wet Disc	Wet Disc
PTO 540	1,000 rpm	1,000 rpm	1,000 rpm

Hydraulics

Name	M126GX	M135GX	M135GXS
Hydraulic Pump Output	77.2 l/min	77.2 l/min	77.2 l/min
3-Point Hitch	Category II	Category II	Category II
Rear Linkage Lift Capacity	6,100 kg	6,100 kg	6,100 kg
Steering	Hydraulic Power Steering	Hydraulic Power Steering	Hydraulic Power Steering

Tyre Options

Name	M126GX	M135GX	M135GXS
AG	done	done	done

Travelling Speeds

Name	M126GX	M135GX	M135GXS
Minimum Low Speed	0.2 km/h	0.74 km/h	0.2 km/h
Maximum High Speed	39.2 km/h	39.2 km/h	39.2 km/h

Dimensions

Name	M126GX	M135GX	M135GXS
Length	4,360 mm	4,400 mm	4,360 mm
Width	2,180 mm	2,130 mm	2,180 mm
Height	2,885 mm	2,885 mm	2,875 mm
Wheelbase	2,690 mm	2,690 mm	2,680 mm
Ground Clearance	615 mm	615 mm	615 mm
Turning Radius	4.1 m	4.1 m	4.1 m
Tractor Weight	4,705 kg	4,705 kg	4,905 kg
