M8540 Narrow ROPS & CAB

Have a similar machine to sell? List yours now for $29.00.

POA POA

Contact Seller in New South Wales

Get answers or find a good time for a test drive. Take the next step and contact the seller.

Request a brochure Can we negotiate on the price?

Add a personal note (optional)

First Name

Email Address

Phone Number

Postcode

Email me price drop and new listings for my search

Receive no-obligation low rate finance quote

First Name

Last Name

Email Address

Phone Number

State

When are you looking to buy a machine?

I agree to the terms & conditions

Getting a quote won't affect your credit score.

Repayment Amount:

Loan Amount:

* Calculated repayment is indicative only.

Find Out More About This Dealer

First Name

Email Address

Phone Number

Postcode

Australian Hammer Supplies

34 Williamson Rd, Ingleburn New South Wales 2565

It is our mission to be New South Wales' most successful Construction & Agricultural Equipment Machinery Company through an absolute commitment to customer service and support.

Australian Hammer Supplies is a family owned and run company specialising in Sales, Parts and Service of Kubota Construction and Agricultural Machinery and Hydraulic Hammers.

Established in 1989, the company has seen significant growth in its operations and sales of Kubota Equipment and Hydraulic Hammers. In 1993 Australian Hammer Supplies became the Australian distributor for Teledyne/Toku Hydraulic Rock Breakers, which is now under the importation of Kubota Tractors Australia.

Price

POA

Need a finance quote?

Getting a quote won't affect your credit score.

Find out more about this dealer?

Tractor

New South Wales

N/A

Details

Vehicle

Kubota

Body Type

Tractor

Condition

New

Cost to Insure

Get a tailored insurance quote with Onesure Insurance Services

34 Williamson Rd, Ingleburn New South Wales 2565

Map

Directions:

Seller's Comment

M8540 Narrow ROPS & CAB

The hydraulics on the M-Series are state-of-the- art. External hydraulic cylinders improve the lifting power and offer easier maintenance. The M8540 offers a large pump capacity of 64.3 l/ m. As a result, the front loader cycle times are short, increasing productivity. The standard 540/540E rpm hydraulic independent PTO (1000 rpm is optional on the M8540) of the Kubota M-Series tractors makes your toughest work easier. Self- modulation engagement with a light touch means implements like a rear cutter engage smoothly. The PTO brake engages when the clutch is shut off and securely holds the PTO shaft. The PTO clutch can be hydraulically engaged and disengaged on the go. This means mowing, operating hay equipment or spraying are all made more efficient. The Category II 3-point hitches provide fast and simple attachment of rear-mounted implements. Lift capacity on the M8540 it is 3900kg at ball ends.

Engine

Name	M8540DCN	M8540DN	M8540NPK
Fuel Type	Diesel	Diesel	Diesel
Cylinders	4	4	4
Engine Model	Kubota V3800	Kubota V3800	Kubota V3800
Engine Gross	84 hp	84 hp	84 hp
PTO	75 hp	75 hp	76 hp
Displacement	3,769 cc	3,769 cc	3,769 cc
Fuel Tank Capacity	78 l	60 l	70 l
Rated Speed	2,600 rpm	2,600 rpm	2,600 rpm

Drive Train

Name	M8540DCN	M8540DN	M8540NPK
Transmission	Synchronized	Synchronized	Synchronized
Ranges	3 Range	3 Range	3 Range
Gears	15F	15F	12F
Drive Method	4WD	4WD	4WD
Brakes	Wet Disc	Wet Disc	Wet Disc
PTO 540	1,000 rpm	1,000 rpm	1,000 rpm

Hydraulics

Name	M8540DCN	M8540DN	M8540NPK
Hydraulic Pump Output	61 l/min	61 l/min	61 l/min
3-Point Hitch	Category II	Category II	Category II
Rear Linkage Lift Capacity	2,300 kg	2,300 kg	2,300 kg
Steering	Hydraulic Power Steering	Hydraulic Power Steering	Hydraulic Power Steering

Tyre Options

Name	M8540DCN	M8540DN	M8540NPK
AG	done	done	done

Travelling Speeds

Name	M8540DCN	M8540DN	M8540NPK
Minimum Low Speed	0.4 km/h	0.4 km/h	0.3 km/h
Maximum High Speed	34.8 km/h	34.8 km/h	21.3 km/h

Dimensions

Name	M8540DCN	M8540DN	M8540NPK
Length	3,680 mm	3,680 mm	3,675 mm
Width	1,440 mm	1,440 mm	1,430 mm
Height	2,260 mm	2,240 mm	2,340 mm
Wheelbase	1,635 mm	2,050 mm	2,153 mm
Ground Clearance	380 mm	380 mm	360 mm
Turning Radius	3.5 m	3.5 m	4 m
Tractor Weight	2,410 kg	2,385 kg	3,000 kg
