Seller's Comment

Wheel Loader R430

The R430 is versatile and powerful and designed to take on a wide range of challenging jobs, with an excellent breakout force and exceptional reach and clearance. The R430 is only available in Canopy model and replaces the previous R420S with some modern updates including a new powerful T4 engine producing 47.6 HP with an increase of 20% compared to the previous R420. The all round performance, versatility and comfort of this machine make this a great addition to the Kubota wheel loader range.

Engine & Maintenance
The R430’s powerful engine produces 47.6 horsepower, a remarkable 20% increase over the R420’s 39.2 horsepower. You’ll appreciate that extra muscle when accelerating, pushing, and climbing hills.

The engine bonnet opens wide to the rear giving you easy convenient access to all the key maintenance points, reducing downtime and costs. The new modern digital display with digital meter is easy-to-read and displays error messages to keep the operator fully informed of loader and engine conditions. Fuel level indication buzzer sounds to prevent overfilling.

Standard Pre Cleaner to keep dust and dirt away from engine and extend filter life while reducing maintenance costs.

Engine
Name
R430
Engine Type
Tier 4 Emission Level
Fuel Type
Diesel
Cylinders
4
Engine Model
Kubota D1803-CR-TIE4-WL5
Engine Net
44.5 HP
Engine Gross
47.6 HP
Displacement
1,826 cc
Rated Speed
2,600 rpm
Drive Train
Name
R430
Transmission
Load Sensing
Brakes
Wet Disc
Hydraulics
Name
R430
Aux Hydraulic Flow
45.4 l/min
Aux Hydraulic Pressure
18.6 psi
Lifting Specifications
Name
R430
Tipping Load Straight With Bucket
2,010 kg
Tipping Load Full Turn With Bucket
1,735 kg
ROC - 50% Tipping Load With Bucket
868 kg
Travelling Speeds
Name
R430
Low
4.8 km/h
High
20 km/h
Dimensions
Name
R430
Length
4,265 mm
Width w/o Bucket
1,520 mm
Height
2,515 mm
Operating Weight - Canopy
3,080 kg
Fluid Capacity
Name
R430
Fuel Reservoir
54 l
Hydraulic System
58 l
Hydraulic Tank
42 l
Operational Specifications
Name
R430
Standard Bucket Capacity
0.4 m3
Breakout Force - Bucket
2,661 kgf
Lifting Capacity At Ground Level
1,734 kgf
Loader Raise Time
4.4 sec
Loader Lower Time
3.3 sec
Working Range
Name
R430
Ground Clearance
280 mm
Wheelbase
1,775 mm
Tread
1,180 mm
Loader Clearance Circle w/ Standard Bucket
3,695 mm
Turning Radius Track Circle
3,085 mm
Bucket Width
1,580 mm
Height To Hinge Pin
2,805 mm
Dump Clearance
2,150 mm
Reach Fully Raised
805 mm
Digging Depth
45 mm
Dump Angle Fully Raised
44 degree
Tilt Back Angle At Travelling Position
51 degree
Articulation Angle
40 degree
Safety Equipment
Name
R430
Canopy
