Wheel Loader R540

The R540 is designed to handle the most challenging jobs with a tough and reliable Kubota engine, excellent breakout force and superior maneuverability. The newly designed cab and multi-function joystick with integrated auxiliary valve switch will keep you working efficiently from start to finish with operator comfort all year round.

Engine & Maintenance
Powered by a Kubota 47.9HP Tier 4 final engine for reliability and features low noise, low vibration and low fuel consumption.

The engine bonnet opens wide to the rear giving you easy convenient access to all the key maintenance points, reducing downtime and costs. The new modern digital display with digital meter is easy-to-read and displays error messages to keep the operator fully informed of loader and engine conditions. Fuel level indication buzzer sounds to prevent overfilling.

Standard Pre Cleaner to keep dust and dirt away from engine and extend filter life while reducing maintenance costs.

Engine
Name
R540 - Cab
Engine Type
Tier 4 Final
Fuel Type
Diesel
Cylinders
4
Engine Model
Kubota V2607-CE-E5-WL
Engine Net
47.9 HP
Engine Gross
51 HP
Displacement
2,615 cc
Rated Speed
2,615 rpm

Drive Train
Name
R540 - Cab
Transmission
Hydrostatic
Brakes
Wet Disc

Hydraulics
Name
R540 - Cab
Aux Hydraulic Flow
54 l/min
Aux Hydraulic Pressure
18.5 psi

Lifting Specifications
Name
R540 - Cab
Tipping Load Straight With Bucket
3,440 kg
Tipping Load Straight With Pallet Forks
2,670 kg
Tipping Load Full Turn With Bucket
3,020 kg
Tipping Load Full Turn With Pallet Forks
2,350 kg
ROC - 50% Tipping Load With Bucket
1,510 kg
ROC - 80% Tipping Load With Pallet Forks
1,880 kg
ROC - 60% Tipping Load With Pallet Forks
1,410 kg

Travelling Speeds
Name
R540 - Cab
Low
0 km/h
High
20 km/h

Dimensions
Name
R540 - Cab
Length
5,895 mm
Width w/o Bucket
1,680 mm
Height
2,480 mm
Operating Weight - Cab
4,520 kg

Fluid Capacity
Name
R540 - Cab
Fuel Reservoir
70 l
Hydraulic System
55 l
Hydraulic Tank
39 l

Operational Specifications
Name
R540 - Cab
Standard Bucket Capacity
0.68 m3
Breakout Force - Bucket
3,712 kgf
Lifting Capacity At Ground Level
3,069 kgf
Loader Raise Time
6.5 sec
Loader Lower Time
4.5 sec

Working Range
Name
R540 - Cab
Ground Clearance
330 mm
Wheelbase
2,000 mm
Tread
1,355 mm
Loader Clearance Circle w/ Standard Bucket
4,145 mm
Turning Radius Track Circle
3,440 mm
Bucket Width
1,820 mm
Height To Hinge Pin
3,230 mm
Dump Clearance
2,525 mm
Reach Fully Raised

730 mm
Digging Depth
110 mm
Dump Angle Fully Raised
45 degree
Tilt Back Angle At Travelling Position
50 degree
Articulation Angle
40 degree

Pallet Fork Specifications
Name
R540 - Cab
Pallet Fork Length
N/A
Overall Length With Forks
5,895 mm
Height Of Forks At Max. Reach
1,370 mm
Height Of Forks At Max. Height
3,030 mm
Reach At Ground Level
810 mm
Max. Reach
1,255 mm
Reach At Max. Height
500 mm

Safety Equipment
Name
R540 - Cab
Cab
