Box Scraper BB25 Series

Land Pride's BB2560, BB2566, BB2572, BB2584 & BB2596 Fixed Bar Box Scrapers are ideal for building sites, feedlots, outdoor arenas, and on farm and ranch lanes or roadways. Two welded braces extending from front to rear of bucket plus welded gussets between the side panels and moldboard provide exceptional strength for keeping the Box Scraper square under heavy loads. Dirt rolls off of the roll-formed moldboard while scraping, creating less drag and you will get twice the wear on the cutting edge due to its reversability.

Specifications

Name	BB2560	BB2566	BB2572	BB2584	BB2596
Min. Horsepower	22 hp	22 hp	22 hp	22 hp	22 hp
Max. Horsepower	55 hp	55 hp	55 hp	55 hp	55 hp
Hitch - Cat I	done	done	done	done	done
Working Width	152 cm	167 cm	182 cm	213 cm	244 cm
Height of Moldboard	432 mm	432 mm	432 mm	432 mm	432 mm
Side Panel Material	10 mm	10 mm	10 mm	10 mm	10 mm
Depth of Bucket	559 mm	559 mm	559 mm	559 mm	559 mm
Overall Length	80 cm	80 cm	80 cm	80 cm	80 cm
Overall Height	88.9 cm	88.9 cm	88.9 cm	88.9 cm	88.9 cm
Weight	214 kg	227 kg	249 kg	269 kg	298 kg
Number of Shanks	5	5	7	7	8
Cutting Edge Width	152 mm	152 mm	152 mm	152 mm	152 mm
Cutting Edge Thickness	13 mm	13 mm	13 mm	13 mm	13 mm
