Seller's Comment

Kubota KX033-4 Compact Excavator

With the stability and lifting capacity of a much bigger machine, the 3-ton class KX033-4 offers a level of performance to efficiently handle a wide variety of tough excavating jobs. An innovative counterbalance ensures superior excavator stability, while the low centre of gravity and double-flanged lower track rollers deliver safe and efficient operation when working to the side with hydraulic attachments or lifting heavy objects.

The Kubota 3-ton class KX033-4 excavator is designed for efficiency, built for stability and created for comfort. With a strong breakout force and exceptional power, the KX033-4 offers a level of performance to handle a wide variety of tough excavating jobs with speed and efficiency.

Engine
Powered by a Kubota 24.8HP Tier 4 engine for reliability and to maximise digging and lifting performance. Easy maintenance as the engine is organised with easy access to primary engine components. Durable steel rear and side panels open easily for quick inspection and routine maintenance to keep machine in peak operating condition. Accumulator helps to change hydraulically driven attachments by clearing residual pressure in the hydraulic lines.

Engine
Name
KX033-4
Engine Type
Interim Tier 4 Emission Level
Fuel Type
Diesel
Cylinders
3
Engine Model
Kubota D1703M
Engine Net
23.9 HP
Engine Gross
24.8 HP
Displacement
1,647 cc
Rated Speed
2,200 rpm

Drive System
Name
KX033-4
Max. Traction Force
2,763 kgf
Tumbler Distance
1,665 mm
Crawler Length
2,100 mm
Shoe Width
300 mm
Ground Contact Pressure - Canopy (Per cm2)
0.307 kgf
Ground Contact Pressure - Cab (Per cm2)
0.321 kgf

Hydraulics
Name
KX033-4
Hydraulic Pump Capacity
39.6 variable x 2 / 20.9 Gear x 1 l/min
Aux Hydraulic Flow - AUX1
60 l/min
Max. Breakout Force - Bucket
3,694 kgf
Max. Breakout Force - Arm
1,756 kgf

Swing System
Name
KX033-4
Swing System
Conventional Swing
Unit Swing Speed
8.9 rpm
Boom Swing Angle Left
70 degree
Boom Swing Angle Right
48 degree

Travelling Speeds
Name
KX033-4
Low
3 km/h
High
4.6 km/h

Dimensions
Name
KX033-4
Length
4,730 mm
Width
1,550 mm
Height - Canopy
2,480 mm
Height - Cab
2,470 mm
Min. Ground Clearance
290 mm
Operating Weight - Canopy
3,365 kg
Operating Weight - Cab
3,511 kg

Blade
Name
KX033-4
Max. Blade Width
1,550 mm
Blade Height
345 mm
Max. Lift Above Ground
365 mm
Max. Drop Below Ground
375 mm

Fluid Capacity
Name
KX033-4
Fuel Reservoir
46.9 l
Hydraulic Oil Reservoir
44.6 l
Hydraulic Oil System
61 l
Engine Oil
5.3 l

Safety Equipment
Name
KX033-4
Operator Station
Canopy

Working Range
Name
KX033-4
Max. Digging Height
4,980 mm
Max. Dumping Height
3,530 mm
Max. Digging Depth
3,210 mm
Max. Vertical Digging Depth
2,235 mm
Max. Digging Radius At Ground
5,120 mm
Max. Digging Radius
5,230 mm
Min. Turning Radius - w/o Swing
2,020 mm
Min. Turning Radius - Swing
1,510 mm
Min. Tail Turning Radius
1,250 mm
