Seller's Comment

Kubota Z200 Series Zero-Turn Mower

Kubota’s residential Z200 Series manoeuvre through landscapes with comfort and ease. Have it all - style, comfort and performance, matched with Kubota’s excellence in quality and durability. Engineered especially for homeowners with exclusive, easy-to-use features and complete with a heavy-duty fabricated mower decks, this innovative mower range offers unmatched comfort with excellent stability, well-placed controls and a low centre of gravity. Select from 5 model variations with 42″, 48″ or 54″ mower deck options.

Engine

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Engine Type	Air-cooled V-Twin	Air-cooled V-Twin	Air-cooled V-Twin	Air-cooled V-Twin	Air-cooled V-Twin
Fuel Type	Petrol	Petrol	Petrol	Petrol	Petrol
Cylinders	2	2	2	2	2
Engine Model	Kawasaki	Kohler	Kawasaki	Kohler	Kawasaki
Engine Gross	21.5 hp	22 hp	21.5 hp	25 hp	24 hp
Displacement	726 cc	725 cc	726 cc	747 cc	726 cc
Fuel Tank Capacity	13.6 l	16.3 l	16.3 l	16.3 l	16.3 l
Rated Speed	3,600 rpm	3,600 rpm	3,600 rpm	3,600 rpm	3,600 rpm

Drive Train

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Transmission	Hydro-Gear ZT2200	Hydro-Gear ZT3100	Hydro-Gear ZT3100	Hydro-Gear ZT3100	Hydro-Gear ZT3100
Drive Method	Integral Type HST, Belt Driven	Integral Type HST, Belt Driven	Integral Type HST, Belt Driven	Integral Type HST, Belt Driven	Integral Type HST, Belt Driven
Brakes	Dry Brakes with Hand Lever Applied/Released Parking Brake	Dry Brakes with Hand Lever Applied/Released Parking Brake	Dry Brakes with Hand Lever Applied/Released Parking Brake	Dry Brakes with Hand Lever Applied/Released Parking Brake	Dry Brakes with Hand Lever Applied/Released Parking Brake
PTO	Belt Drive with Ogura GT1A Electric Clutch	Belt Drive with Ogura GT1A Electric Clutch	Belt Drive with Ogura GT1A Electric Clutch	Belt Drive with Ogura GT1A Electric Clutch	Belt Drive with Ogura GT1A Electric Clutch

Tyre Size

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Front	11×4-5	13x6.5-6	13x6.5-6	13x6.5-6	13x6.5-6
Rear	18×7.5-10	22x10-14	22×10-14	22×10-14	22×10-14

Travelling Speeds

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Max. Forward Speed	10.5 km/h	12.9 km/h	12.9 km/h	12.9 km/h	12.9 km/h
Max. Reverse Speed	6.4 km/h	6.4 km/h	6.4 km/h	6.4 km/h	6.4 km/h

Mower Deck

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Model	RCK42P-122Z	RCK48P-200Z	RCK48P-1200Z	RCK54P-200Z	RCK54P-200Z
Mower Lift System	Mechanical	Mechanical	Mechanical	Mechanical	Mechanical
Mower Deck Type	Pro commercial fabricated	Pro commercial fabricated	Pro commercial fabricated	Pro commercial fabricated	Pro commercial fabricated
Deck Depth	114 mm	127 mm	127 mm	127 mm	127 mm
Belt Type	Single belt	Single belt	Single belt	Single belt	Single belt
Deck Steel Thickness	3.4 mm	3.4 mm	3.4 mm	3.4 mm	3.4 mm
Cutting Width	42 in.	48 in	48 in.	54 in.	54 in.
Number of Blades	2	3	3	3	3
Cutting Height	1.5 in. - 4.25 in. 1/4" increments in.	1.5 in. - 4.5 in. 1/4" increments in.	1.5 in. - 4.5 in. 1/4" increments in.	1.5 in. - 4.5 in. 1/4" increments in.	1.5 in. - 4.5 in. 1/4" increments in.
Mower Mounting System	Parallel linkage	Parallel linkage	Parallel linkage	Parallel linkage	Parallel linkage
Blade Tip Speed Max.	17,700 fpm	18,100 fpm	18,100 fpm	18,100 fpm	18,100 fpm

Grass Catcher - Optional

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Bag Type	2 bag, Manual dump	2 bag, Manual dump	2 bag, Manual dump	2 bag, Manual dump	2 bag, Manual dump
Bag Capacity	140 l	211 l	211 l	211 l	211 l

Dimensions

Name	Z232KW-42	Z242KH-48	Z242KW-48	Z252KH-54	Z252KW-54
Length	1,890 mm	2,006 mm	2,006 mm	2,006 mm	2,006 mm
Width	1,400 mm	1,552 mm	1,552 mm	1,710 mm	1,710 mm
Height (w/ ROPS Upright)	1,693 mm	1,855 mm	1,738 mm	1,855 mm	1,738 mm
Wheelbase	1,236 mm	1,195 mm	1,195 mm	1,195 mm	1,195 mm
Ground Clearance	104 mm	110 mm	110 mm	110 mm	110 mm
Tread Front	616 mm	826 mm	826 mm	826 mm	826 mm
Tread Rear	885 mm	964 mm	964 mm	964 mm	964 mm
Weight	292 kg	368 kg	383 kg	375 kg	390 kg
