Grooming Mowers FDR16 Series
Land Pride Grooming Mowers are a rear-mount alternative to a belly-mount mower for your subcompact and compact tractor. With three fixed blades and a floating 3-Point hitch, these mowers give you a clean cut in fescue and other turf-type grasses.
Specifications
| Name |
FDR1648 |
FDR1660 |
FDR1672 |
| Horsepower |
15-40 hp |
15-40 hp |
15-40 hp |
| Weight |
220 kg |
262 kg |
281 kg |
| Deck Material Thickness |
3/16 " |
3/16 " |
3/16 " |
| Front Roller |
Optional |
Optional |
Optional |
Dimensions
| Name |
FDR1648 |
FDR1660 |
FDR1672 |
| Working Width |
122 cm |
152 cm |
183 cm |
| Overall Width |
130 cm |
160 cm |
190 cm |
| Cutting Height (min) |
3/4 " |
3/4 " |
3/4 " |
| Cutting Height (max) |
5-1/4 " |
5-1/4 " |
5-1/4 " |
Hitch
| Name |
FDR1648 |
FDR1660 |
FDR1672 |
| Hitch |
Cat. I |
Cat. I |
Cat. I |
| Quick Hitch Compatible |
close |
done |
done |
Blades
| Name |
FDR1648 |
FDR1660 |
FDR1672 |
| Blade material |
Heat Treated Alloy Steel |
Heat Treated Alloy Steel |
Heat Treated Alloy Steel |
| Number of blades |
4 |
4 |
4 |
| Blades (length) |
1/4 " |
1/4 " |
1/4 " |
| Blades (width) |
2-1/2 " |
2-1/2 " |
2-1/2 " |
| Blades (height) |
16-7/8 " |
21 " |
25 " |
| Blade overlap |
1-1/4 " |
1-1/4 " |
1-1/4 " |
| Blade spindles |
Greasable |
Greasable |
Greasable |
| Blade tip speed |
16,203 fpm |
18,195 fpm |
18,130 fpm |
Tyres
| Name |
FDR1648 |
FDR1660 |
FDR1672 |
| Number of wheels |
4 |
4 |
4 |
| Wheel type |
Castered gauge wheel |
Castered gauge wheel |
Castered gauge wheel |
| Tire material |
Solid rubber |
Solid rubber |
Solid rubber |
| Wheel (width) |
3-1/4 " |
3-1/4 " |
3-1/4 " |
| Wheel (height) |
10 " |
10 " |
10 " |
| Castered Wheel Spindle (diameter) |
1 " |
1 " |
1 " |
Drive Train
| Name |
FDR1648 |
FDR1660 |
FDR1672 |
| Speed |
540 rpm |
540 rpm |
540 rpm |
| Section |
B |
B |
B |
| Belt |
V |
V |
V |
| Driveline |
Heavy duty with quick coupler |
Heavy duty with quick coupler |
Heavy duty with quick coupler |
