Seller's Comment

Box Scraper BB35 Series

Land Pride's BB3578, BB3584 & BB3596 Box Blades are a heavier 3-point Box Blade to complement our popular line of Box Blades offered by Land Pride. The beefy 3/8" x 4" x 4" main-frame tube and 3/8" end panels makes our 35 Series Fixed Bar Box Scraper ideal for construction sites and commercial operations or for use by counties and municipalities. Two welded channel braces extend from front to rear of the box plus welded gussets between the side panels and 23" roll-formed moldboard provide exceptional strength under heavy loads. The durable BB35 is comfortable dragging or back-filling.

Specifications

Name	BB3578	BB3584	BB3596
Min. Horsepower	45 hp	45 hp	45 hp
Max. Horsepower	120 hp	120 hp	120 hp
Hitch - Cat I	done	done	done
Hitch - Cat II	done	done	done
Working Width	198 cm	213 cm	244 cm
Height of Moldboard	584 mm	584 mm	584 mm
Side Panel Material	10 mm	10 mm	10 mm
Depth of Bucket	889 mm	889 mm	889 mm
Overall Length	112 cm	112 cm	112 cm
Overall Height	90.2 cm	90.2 cm	90.2 cm
Weight	374 kg	388 kg	424 kg
Number of Shanks	7	7	8
Cutting Edge Width	152 mm	152 mm	152 mm
Cutting Edge Thickness	13 mm	13 mm	13 mm
Bucket Capacity	0.85 m3	0.91 m3	1.1 m3
