Rotary Tillers RTA12 Series
Land Pride's RTA12 Series forward rotation Rotary Tillers are a great seedbed preparation tool. With uses in rural and non-rural applications like landscaping and gardening, the 12 Series Rotary Tillers offer an economical yet durable tilling solution. These units feature a- 3 year gearbox warranty, 10 year chain and sprocket warranty, and 6-1/2" tilling depth. Look for the RTR12 Series for your reverse rotation alternative.
Specifications
| Name | RTA1242 | RTA1250 | RTA1258 | RTA1266 | RTA1274 | RTA1282 |
|---|---|---|---|---|---|---|
| Horsepower | 15-40 hp | 15-40 hp | 20-50 hp | 20-50 hp | 25-60 hp | 30-60 hp |
| Weight | 177 kg | 191 kg | 203 kg | 216 kg | 228 kg | 250 kg |
| Number of Flanges | 5 | 6 | 7 | 8 | 9 | 10 |
| Skid shoe setting | 7 | 7 | 7 | 7 | 7 | 7 |
| Rotor shaft speed (at 540rpm PTO) | 211 rpm | 211 rpm | 211 rpm | 211 rpm | 211 rpm | 211 rpm |
| PTO driveline category | 3 | 3 | 3 | 3 | 3 | 3 |
| PTO driveline protection | Slip clutch | Slip clutch | Slip clutch | Slip clutch | Slip clutch | Slip clutch |
| Gearbox rating | 60 hp | 60 hp | 60 hp | 60 hp | 60 hp | 60 hp |
| Gearbox speed | 540 rpm | 540 rpm | 540 rpm | 540 rpm | 540 rpm | 540 rpm |
| Gearbox design | Cast iron housing/drain plug | Cast iron housing/drain plug | Cast iron housing/drain plug | Cast iron housing/drain plug | Cast iron housing/drain plug | Cast iron housing/drain plug |
| Drive chain | #80 high tensile in oil bath | #80 high tensile in oil bath | #80 high tensile in oil bath | #80 high tensile in oil bath | #80 high tensile in oil bath | #80 high tensile in oil bath |
| Sprockets | Hardened teeth, splined center | Hardened teeth, splined center | Hardened teeth, splined center | Hardened teeth, splined center | Hardened teeth, splined center | Hardened teeth, splined center |
Dimensions
| Name | RTA1242 | RTA1250 | RTA1258 | RTA1266 | RTA1274 | RTA1282 |
|---|---|---|---|---|---|---|
| Width (endplate to endplate) | 107 cm | 127 cm | 147 cm | 168 cm | 188 cm | 208 cm |
| Overall Width | 47-3/8 " | 55-3/8 " | 63-3/8 " | 71-3/8 " | 79-3/8 " | 87-1/8 " |
| Rotor swing diameter | 15 " | 15 " | 15 " | 15 " | 15 " | 15 " |
| Max. tilling depth | 6-1/2 " | 6-1/2 " | 6-1/2 " | 6-1/2 " | 6-1/2 " | 6-1/2 " |
Hitch
| Name | RTA1242 | RTA1250 | RTA1258 | RTA1266 | RTA1274 | RTA1282 |
|---|---|---|---|---|---|---|
| Hitch | Cat.1 | Cat.1 | Cat.1 | Cat.1 | Cat.1 | Cat.1 |
Blades
| Name | RTA1242 | RTA1250 | RTA1258 | RTA1266 | RTA1274 | RTA1282 |
|---|---|---|---|---|---|---|
| No. of blades per flange | 4 | 4 | 4 | 4 | 4 | 4 |
| Blade shape | C-shape | C-shape | C-shape | C-shape | C-shape | C-shape |
| Blade spacing | 7-7/8 " | 7-7/8 " | 7-7/8 " | 7-7/8 " | 7-7/8 " | 7-7/8 " |
