FEATURES OF THE TYM 'T1003' 4WD CABIN TRACTOR

ENGINE

• Powered by 99.5hp Perkins 4 cylinder Diesel engine
• Fuel efficient, reliable. powerful and rugged engine
• 4400cc engine for high performance in heavy duty applications
• Dual dry element air cleaner for Australia's dusty conditions

• 126 litre fuel tank capacity will provide for many working hours
• Easy access from ground level

DRIVELINE

• The tractor weight of 3685kg is a reflection of the heavy duty transmission, driveline and axles. The tractor weight is, in part, a result of the heavy front axle, which is important for a tractor fitted with a front end loader as substantial loads are applied during loader operation

• 32 forward / 32 reverse manual powershuttle allows you to shift forward and reverse without using a clutch
• Powershuttle allows you to shift forward and reverse without using a clutch
• 4 Ranges with range lever located to operator's right
• 0-40km/h maximum speed

• The heavy duty front axle performs in tough working conditions and handles loads with ease

• Rear axle with diff-lock for difficult traction situations
• 4WD and the diff-lock provides better traction, control and performance
• 4WD mode is controlled by a lever on the left hand side of the operator

• Inboard wet disc brakes can be split for indpendent left and right side braking to assist turning in tight situations

PTO, HYDRAULICS & LINKAGE

• Control for the linkage and hydraulic remotes are on the right-hand side with Bosch electronic linkage controls
• Adjustable linkage lift speed
• Soft ride transport mode on linkage

• 3-point linkage with quick attach lower link arms
• Linkage arms with simple pin adjustable sway position
• 3-point linkage with 3110kg lifting capacity gives the tractor great versatility and range of applications
• Adjustable lower link stabiliser arms

• External button for ease of operating 3 point hitch out of cab

• 3 sets of double-acting hydraulic remotes
• The PTO driveline is a simple and direct design for high efficiency and power
• The PTO clutch is an independent oil immersed clutch pack for long life with simple push-button operation

• Auto-PTO function automatically disengages the PTO when the linkage is raised, and automatically re-engages when lowered; a great function that simplifies repeated row work and prevents implement damage

• Adjustable front and rear wheels to vary or widen track width for steep conditions to improve stability

OPERATOR AREA

• Wide door entry for easy access
• Uncluttered flat floor without trip hazards
• Rubber floor mat reduces noise and provides an easy to maintain surface
• Plenty of leg room
• Sunroof

• Ergonomic design with easy to reach controls
• Easy to read instrument panel
• Combination switch controls lights and indicators
• Digital forward speed display

• Tiltable steering wheel

• Fully integrated joystick for control of front end loader with electric button for third function operation (when loader is fitted)

• Adjustable air suspension seat with arm and headrest for comfort

• Air-conditioned cabin with heating
• Radio/MP3/USB/SD Player
• Internal and external rear vision mirrors

• Rear windscreen wiper & washer
• Rear external cabin work lights

MAINTENANCE

• Pop-up 1 piece bonnet
• Easy access to all maintenance areas including battery
• Radiator with removable screen to prevent clogging
