Power Harrow PH2000F Series

Have a similar machine to sell? List yours now for $29.00.

POA POA

Contact Seller in New South Wales

Get answers or find a good time for a test drive. Take the next step and contact the seller.

Request a brochure Can we negotiate on the price?

Add a personal note (optional)

First Name

Email Address

Phone Number

Postcode

Email me price drop and new listings for my search

Receive no-obligation low rate finance quote

First Name

Last Name

Email Address

Phone Number

State

When are you looking to buy a machine?

I agree to the terms & conditions

Getting a quote won't affect your credit score.

Repayment Amount:

Loan Amount:

* Calculated repayment is indicative only.

Find Out More About This Dealer

First Name

Email Address

Phone Number

Postcode

Australian Hammer Supplies

34 Williamson Rd, Ingleburn New South Wales 2565

It is our mission to be New South Wales' most successful Construction & Agricultural Equipment Machinery Company through an absolute commitment to customer service and support.

Australian Hammer Supplies is a family owned and run company specialising in Sales, Parts and Service of Kubota Construction and Agricultural Machinery and Hydraulic Hammers.

Established in 1989, the company has seen significant growth in its operations and sales of Kubota Equipment and Hydraulic Hammers. In 1993 Australian Hammer Supplies became the Australian distributor for Teledyne/Toku Hydraulic Rock Breakers, which is now under the importation of Kubota Tractors Australia.

Price

POA

Need a finance quote?

Getting a quote won't affect your credit score.

Find out more about this dealer?

Harrow

New South Wales

N/A

Details

Vehicle

Kubota

Make

Kubota

Body Type

Harrow

Condition

Used

State

New South Wales

Cost To Insure

Get a tailored insurance quote with Onesure Insurance Services

34 Williamson Rd, Ingleburn New South Wales 2565

Map

Directions:

Seller's Comment

Power Harrow PH2000F Series

The Kubota PH2000F Series are folding power harrows with working widths from 4 m to 6 m, suitable for large-scale farming. An innovative trough design means that no lateral frame is required, which saves weight and simplifies set-up. There are 4 rotors per metre of trough, and optimum tillage and low power consumption is achieved by the closer inter-tine carrier distances (250 mm). Helical tine configuration and 95 mm rotor clearance allow perfect soil levelling and preparation.

Dimensions & Weight

Name	PH2400F	PH2500F	PH2600F
Working Width	4 m	5 m	6 m
Transport Width	2.5 m	2.5 m	2.5 m
Weight w/575mm Packer Roller	2,590 kg	3,290 kg	3,690 kg

Attachment to Tractor

Name	PH2400F	PH2500F	PH2600F
PTO Input Speed	1,000 rpm	1,000 rpm	1,000 rpm
Min. Power Required PTO	130 hp	130 hp	130 hp
Max. Power Allowed PTO	300 hp	300 hp	300 hp
Oscillating Lower Link Size	Cat III	Cat III	Cat III

Specifications

Name	PH2400F	PH2500F	PH2600F
Overload Protection (per each side drive)	Automatic Clutch	Automatic Clutch	Automatic Clutch
No. of Rotors	16	20	24
No. of Tines	32	40	48
Tine Size	15 x 330 mm	15 x 330 mm	15 x 330 mm
Max. Working Depth	280 mm	280 mm	280 mm
Rotor Speed	336 rpm	336 rpm	336 rpm
Depth Control (Cage Roller)	550 mm dia.	550 mm dia.	550 mm dia.
Depth Control (Packer Roller)	575 mm dia.	575 mm dia.	575 mm dia.

Standard Extras

Name	PH2400F	PH2500F	PH2600F
Tines	Quick Fit Carbide (Hard Faced)	Quick Fit Carbide (Hard Faced)	Quick Fit Carbide (Hard Faced)
Drive Shaft	1-3/8" - 6 Spline 1000rpm (Walterscheid) Lateral PTO w/Auto Clutch	1-3/8" - 6 Spline 1000rpm (Walterscheid) Lateral PTO w/Auto Clutch	1-3/8" - 6 Spline 1000rpm (Walterscheid) Lateral PTO w/Auto Clutch
Depth Control Adjustment	Hydraulic Parallelogram w/Spacers	Hydraulic Parallelogram w/Spacers	Hydraulic Parallelogram w/Spacers
Levelling	Rear Levelling Bar	Rear Levelling Bar	Rear Levelling Bar
