Track Loader

New South Wales

N/A

Details

Vehicle

Kubota SVL75-3

Make

Kubota

Model

SVL75-3

Body Type

Track Loader

Condition

New

State

New South Wales

Cost To Insure

Get a tailored insurance quote with Onesure Insurance Services

34 Williamson Rd, Ingleburn New South Wales 2565

Map

Directions:

Seller's Comment

Track Loader SVL75-3

The all new SVL75-3 replaces the proven SVL75-2 and is Kubota's latest track loader with a wide range of new features, improving performance and comfort. Powered by a Kubota 74.3HP engine and now with higher torque, the SVL75-3 can take on any task whether that's digging, dumping, grading or moving materials. Other new features include a new one-piece cabin, advanced hydraulic system, 7" LCD touch screen with keyless start and integrated reverse camera, updated engine layout design and much more including the well-known front sliding window. The standard flow and high-flow models allow you to operate a variety of attachments from our SSV & SVL performance matched attachments range.

One-Piece Pressurised Cabin
The SVL75-3 now features a fully sealed one-piece pressurised cabin, preventing any dirt, dust, water or any debris ingression, allowing a clean environment for the operator. The luxurious cab delivers operator comfort with a wide entrance, ergonomically designed controls and front sliding window to easily enter and exit the cabin. There are also 6 vents consistently placed throughout the cabin improving A/C or heating flow, ensuring optimal working conditions all year round. Further to this, the A/C filter is positioned at the top of the cab which filters clean air through the cabin.

Engine
Name
SVL75-3
Engine Type
Tier 4 Stage 5 Emission Level
Fuel Type
Diesel
Cylinders
4
Engine Model
Kubota V3307-TE5A-CTL-Q
Engine Net
73.2 HP
Engine Gross
74.3 HP
Displacement
3,331 cc
Rated speed
2,400 rpm
Undercarriage
Name
SVL75-3
Track Width - Standard
320 mm
Track Width - Wide
400 mm
Ground Pressure Cab - Standard Track
5.9 psi
Ground Pressure Cab - Wide Track
4.8 psi
Track Roller (Per Side)
4
Track Ground Contact Length
1,436 mm
Traction Force
4,390 kg
Min. Ground Clearance
296 mm
Hydraulics
Name
SVL75-3
Aux Hydraulic Flow - Standard
72.7 l/min
Aux Hydraulic Flow - High
112.8 l/min
Loader Hydraulic Pressure (Per cm2)
224 kgf
Loader Performance
Name
SVL75-3
ROC - 35% Tipping Load
1,129 kg
Tipping Load
3,226 kg
Breakout Force - Bucket
2,808 kg
Breakout Force - Lift Arm
2,142 kg
Lifting Capacity
2,214 kg
Lift Arm Path
Vertical
Travelling Speeds
Name
SVL75-3
Low
9 km/h
High
13.7 km/h
Dimensions
Name
SVL75-3
Length
2,844 mm
Width - Standard Track
1,675 mm
Width - Wide Track
1,755 mm
Height
2,078 mm
Operating Weight - Cab
4,273 kg
Fluid Capacity
Name
SVL75-3
Fuel Reservoir
94.6 l
Hydraulic System
46 l
Hydraulic Tank
16.1 l
Safety Equipment
Name
SVL75-3
Cab
Open Cab
Front Sliding Window
