Grading Scraper GS05 Series

Land Pride GS0548 & GS0560 Grading Scrapers have uses and applications in landscaping, hobby farms, and small estates and are a low cost alternative for road grading applications. They do not require the additional horsepower or tending of tractor 3-point lift controls that a box scraper normally requires. Simply setting a properly adjusted GS05 Series Grading Scraper on the ground and driving forward enables the operator to grade off high spots and fill in ruts and low spots on unimproved roads and lanes with little or no manipulation of the tractors 3-point hitch controls. Unlike a rear blade, they require no adjustment of blade angling or offset positions.

Specifications

Name	GS0548	GS0560
Min. Horsepower	18 hp	18 hp
Max. Horsepower	33 hp	33 hp
Hitch - Cat I	done	done
Working Width	122 cm	152 cm
Side Panel Thickness	4.7 mm	4.7 mm
Skid Shoe Thickness	6 mm	6 mm
Number of Shank Positions	3	3
Cutting Edge Width	152 mm	152 mm
Cutting Edge Thickness	10 mm	10 mm
Cutting Edge Adjustment	Fixed	Fixed
Weight	141 kg	159 kg
