Toku Large Hammers

Toku’s large TNB hydraulic breaker range are suited to excavators from 20 to 70 tonne. Nothing stands in the way of a Toku, with powerful impact force to get the job done efficiently and long product life for years of dependable use. Created for a wide range of applications, Toku’s large TNB range is ideal for demolition work, civil construction, mining and much more.

CUSHION CHAMBER

Important impact source since TNB-breakers source its Impact Energy 70% from Nitrogen Gas Pressure of cushion chamber and the rest of 30% from the Operation Oil Circuit.

AUTO GREASING SYSTEM

New standard Auto Greasing System for models TNB-7J, TNB-151LU2, TNB-230LU2, TNB-310LU2 and TNB-400LU2

ACCUMULATOR FREE BREAKER STRUCTURE

Allows easy and low cost maintenance.

DUST PREVENTING VALVE

Takes cleaner air from upper area into the impact chamber and blows out the dusty air to bottom. This valve port is also used for
Underwater Application to lead the high pressure air from a compressor.

GREASE SUPPLY

Direct and Independent Grease Supply to Chisel Bush and Chisel Holder Bush. A chisel is the most consumed item and this system contributes well for the long life of chisel.

DURABLE SIDE BOLTS

Stress scattered structure and partially rubber coated for anti-vibration.

SHORT OIL PATH

The oil path between control valve and cylinder is taken shortest as less as possible to avoid any secondary trouble.

LONG STROKE PISTON

Gives more powerful impact energy and brings a stable breaker operation.

DUAL OVAL RETAINER PINS

Robust and guarantees correct tool alignment and long life.

50/50 PISTON TO TOOL WEIGHT RATIO

Efficiently transfers blow energy into the material and reduces recoil.

Working Weight

Name	TNB-230LU2	TNB-310LU1	TNB-40K	TNB-400LU2
Working Weight - Top Mount Type	close	close	close	close
Working Weight - Box Type	2,740 kg	3,600 kg	3,850 kg	4,700 kg

Dimensions

Name	TNB-230LU2	TNB-310LU1	TNB-40K	TNB-400LU2
Width	650 mm	680 mm	630 mm	680 mm
Height	2,821 mm	3,312 mm	3,524 mm	3,647 mm
Tool Diameter	146 mm	160 mm	170 mm	178 mm
Tool Length	1,180 mm	1,360 mm	1,500 mm	1,540 mm
Min. Carrier Range	27 ton	38 ton	38 ton	45 ton
Max. Carrier Range	40 ton	50 ton	53 ton	70 ton

Hydraulics

Name	TNB-230LU2	TNB-310LU1	TNB-40K	TNB-400LU2
Min. Impact Rate	380 bpm	370 bpm	290 bpm	370 bpm
Max. Impact Rate	450 bpm	470 bpm	440 bpm	470 bpm
Min. Oil Flow	180 l/min	240 l/min	240 l/min	280 l/min
Max. Oil Flow	230 l/min	300 l/min	300 l/min	390 l/min
Min. Operating Pressure	13 MPa	14 MPa	14 MPa	14 MPa
Max. Operating Pressure	18 MPa	18 MPa	18 MPa	18 MPa
Hose Size	1 inch	1" 1/4 inch	1 inch	1" 1/4 inch
Gas Pressure	0.8 MPa	0.8 MPa	1 MPa	0.8 MPa

Design Features

Name	TNB-230LU2	TNB-310LU1	TNB-40K	TNB-400LU2
Auto Greasing System	done	done	done	done
