Seller's Comment

MX5200 utility tractor

Kubota’s MX5200 utility tractor is designed to tackle almost any task and with our HST model (MX5200HD), those tasks just got easier. Kubota’s new MX5200 HST model features hydraulic servo systems that increase pedal responsiveness, providing easy pedal-shifting operation for smoother performance and improved control regardless of load size. Forward and reverse directional changes are simple. HST also reduces shock, vibration, noise and fatigue to improve tractor performance and operator comfort. With the net power of Kubota’s 50HP engine, the MX5200 is a highly responsive workhorse, ready for tough jobs. Of course, our standard, “gear-drive” model provides the same reliable versatility you’ve come to know and expect from Kubota.

Engine

Name	MX5200D	MX5200HD
Fuel Type	Diesel	Diesel
Cylinders	4	4
Engine Model	Kubota V2403	Kubota V2403
Engine Gross	50 hp	50 hp
PTO	44 hp	42.5 hp
Displacement	2,434 cc	2,434 cc
Fuel Tank Capacity	48 l	48 l
Rated Speed	2,700 rpm	2,700 rpm

Drive Train

Name	MX5200D	MX5200HD
Transmission	Synchronized	Hydrostatic
Ranges	2 Range	3 Range
Gears	8F	8F
Drive Method	4WD	4WD
Brakes	Wet Disc	Wet Disc
PTO 540	2,700 rpm	2,700 rpm

Hydraulics

Name	MX5200D	MX5200HD
Hydraulic Pump Output	35.8 l/min	35.8 l/min
3-Point Hitch	Category II	Category II
Rear Linkage Lift Capacity	1,300 kg	1,300 kg
Steering	Hydraulic Power Steering	Hydraulic Power Steering

Tyre Options

Name	MX5200D	MX5200HD
AG	done	done
Industrial	done	done
Turf	done	done

Travelling Speeds

Name	MX5200D	MX5200HD
Minimum Low Speed	1.6 km/h	0 km/h
Maximum High Speed	25.9 km/h	25.9 km/h

Dimensions

Name	MX5200D	MX5200HD
Length	3,315 mm	3,120 mm
Width	1,770 mm	1,770 mm
Height	2,430 mm	2,430 mm
Wheelbase	1,895 mm	1,895 mm
Ground Clearance	385 mm	405 mm
Turning Radius	2.7 m	2.7 m
Tractor Weight	1,615 kg	1,712 kg
